Neutrik - NL8MM - 8 pole speakON feedthrough adapter for cable extensions.
by Neutrik
Currently Out Of Stock
$71.00
SKU NL8MM
8 pole speakON feedthrough adapter for cable extensions
Technical Information
Product | |
Title | NL8MM |
Connection Type | Adapter |
Gender | male |
Electrical | |
Contact resistance | ? 3 m? (after lifetime) |
Dielectric strength | 4 kVdc (peak) |
Insulation resistance | > 1 G? (after dampheat) |
Rated current per contact | 15 A rms continuous |
Rated current per contact | 30 A audiosignal, duty cycle 50 % |
Rated voltage | 250 V (Insulation) |
Attention | speakON is NOT to be used as an AC mains or power supply connector! |
Mechanical | |
Lifetime | > 5000 mating cycles |
Wiresize | |
Locking device | Quick Lock |
Material | |
Contact plating | 4 ?m Ag |
Contacts | Bronze (CuSn6) |
Insert | Polyamide (PA 6 30 % GR) |
Shell | Polyamide (PA 6 30 % GR) |
Environmental | |
Flammability | UL 94 HB |
Solderability | Complies with IEC 68-2-20 |
Temperature range | -30 ?C to +80 ?C |
