ARX - Iso Later Duo - Dual Transformer Transformer Isolater

by ARX
$511.00

ISO Later

A transformer isolated de-coupler, for removinging Ground loops and for use in applications where complete Galvanic isolation is required, eg Broadcast feeds, remote recording

Available in Single Channel or Double Header format. The heavy duty all-steel chassis is finished in attractive matt textured powdercoat, with hardwearing epoxy screen printing and slip resistant rubber pads.
The ISO Later is a totally passive device with no power requirements, making it a truly universal problem solver.
Security features include Kensington®-type computer lock slot and optional bracket kit for under-table mounting.

Available in Single Channel or Double Header format.

Specifications:

Input Impedance: 600 Ohms
Output Impedance: 600 Ohms
Frequency Response: 20Hz - 20 KHz ± 0.1dB
Maximum Output Level: + 24dBm
THD at Max Output: 0.2% 30 Hz - 20KHz
Insertion Loss: 0.75dB @ 1 KHz (600 Ohm source & load)
Input Connectors: 3 pin female XLR wired Pin 2 + Hot, Pin 3 – Cold
Output Connectors: 3 pin male XLR wired Pin 2 + Hot, Pin 3 – Cold. Audio grounds are unconnected
Ground Reference: Chassis is grounded to Output Pin 1; Duo version chassis is grounded to Channel 1 Output Pin 1
Construction: All-steel chassis, fibreglass PCB, ultra low noise audio transformer
