Finally, a 12 inch speaker voiced specifically for fiddle. Reduced bow friction noise and tame upper-mids. It?s also great for guitar if you want thick tone with warm, smooth, more mellow mids and highs.



SPECIFICATION
Nominal Basket Diameter 12", 305 mm
Nominal Impedance* 8 Ω
Power Rating*
Program Power N/A
Watts 100 W
Resonance 82 Hz
Usable Frequency Range 80 Hz - 4.5 kHz
Sensitivity* 100.1 dB
Magnet Weight 38 oz.
Gap Height 0.313", 8 mm
Voice Coil Diameter 2", 51 mm
THIELE & SMALL PARAMETERS
Resonant Frequency (fs) 82 Hz
DC Resistance (Re) 7.34 Ω
Coil Inductance (Le) 0.63m H
Mechanical Q (Qms) 15.49
Electromagnetic Q (Qes) 0.58
Total Q (Qts) 0.56
Compliance Equivalent Volume (Vas) 57.81 liters / 2.04 cu.ft.
Peak Diaphragm Displacement Volume (Vd) 43.1 cc
Mechanical Compliance of Suspension (Cms) 0.14 mm/N
BL Product (BL) 13.11 T-M
Diaphragm Mass Inc. Airload (MMs) 26 grams
Efficiency Bandwidth Product (EBP) 141
Maximum Linear Excursion (Xmax) 0.79 mm
Surface Area of Cone (Sd) 545.4 cm2
Maximum Mechanical Limit (Xlim) 0 mm
MOUNTING INFORMATION
Recommended Enclosure Volume
Sealed N/a
Vented N/a
Driver Volume Displaced 0 cu.ft. / 0 liters
Overall Diameter 12.17", 309.1 mm
Baffle Hole Diameter 11.13", 282.7 mm
Front Sealing Gasket Yes
Rear Sealing Gasket Yes
Mounting Holes Diameter 0.24", 6.1mm
Mounting Holes B.C.D. 11.75", 298.5mm
Depth 5.13", 130.2 mm
Net Weight 7.9 lbs, 3.58 kg
Shipping Weight 9.8 lbs, 4.45 kgs
MATERIALS OF CONSTRUCTION
Coil Construction Copper voice coil
Coil Former Polyimide former
Magnet Composition
Core Details Non-vented core

Basket Materials Pressed steel basket
Cone Composition
Cone Edge Composition Full molded paper
Dust Cap Composition Zurette dust cap
