Neutrik - NC3FM-C-B - Unisex XLR Cable Connector
SKU NC3FM-C-B
World's first 3 pole unisex XLR cable connector, black
Features & Benefits
- World's first unisex XLR
- 3 pole male and female cable connector in one housing
- Easy selectable gender?- converted by sliding housing back and forth
- Substitute adapters, ideal as an emergency kit
- With all benefits of the XLR XX series
- Branded with unique hologram - guarantees genuine and authentic Neutrik product
Technical Information
| Title |
NC3FM-C-B |
| Connection Type |
XLR |
| Gender |
female |
| Capacitance between contacts |
? 4 pF |
| Contact resistance |
? 3 m? |
| Dielectric strength |
1.5 kVdc |
| Insulation resistance |
> 2 G? (initial) |
| Rated current per contact |
16 A |
| Rated voltage |
<50 V |
| Cable O.D. |
3.5 - 8.0 mm |
| Insertion force |
? 20 N |
| Withdrawal force |
? 20 N |
| Lifetime |
> 1000 mating cycles |
| Wiresize |
max. 2.5 mm? |
| Wiresize |
max. 14 AWG |
| Wiring |
Solder contacts |
| Locking device |
Latch lock |
| Boot |
Polyurethan |
| Contact plating |
0.2 ?m Au |
| Contacts |
Brass (CuZn39Pb3) (male) |
| Insert |
Polyamdie (PA 6.6 30 % GR) |
| Locking element |
Zinc diecast (ZnAl4Cu1) / Ck 67 (spring) |
| Shell |
Black chromium |
| Shell plating |
Nickel |
| Strain relief |
Polyacetal (POM) |
| Flammability |
UL 94 HB |
| Standard compliance |
IEC 61076-2-103 |
| Protection class |
IP 40 |
| Solderability |
Complies with IEC 68-2-20 |
| Temperature range |
-30 ?C to +80 ?C |
