Neutrik - NL8MMXX - 8 Pole SpeakON Feedthrough Coupler For Cable Extensions.
SKU NL8MMXX
8 pole speakON feedthrough coupler for cable extensions
Product |
|
Title |
NL8MMXX |
Connection Type |
Adapter |
Gender |
male |
Electrical |
|
Contact resistance |
< 3 mΩ |
Dielectric strength |
1.5 kVac |
Insulation resistance |
> 0.1 GΩ (after dampheat) |
Rated current per contact |
25 A rms continuous |
Rated voltage |
250 V ac |
Attention |
speakON is NOT to be used as an mains or power supply connector (AC / DC)! |
Mechanical |
|
Lifetime |
> 5000 mating cycles |
Locking device |
Quick Lock |
Material |
|
Contact plating |
Ag |
Contacts |
Copper Alloy |
Shell |
Zinc diecast, black chrome plated |
Insert |
Polyamide (PA 6.6) |
Environmental |
|
Temperature range |
-30 °C to +80 °C |
Flammability |
UL 94 V-0 |
