MX6CPOE

2-Way 6" POE High-Fidelity Ceiling Speaker

The MX6CPOE is a PoE-enabled version of  the MX6C in-ceiling loudspeaker, designed for network-centric audio systems using Dante® and PoE distribution. By integrating a high-performance Class-D amplifier directly onto the loudspeaker, it allows audio, power, and control to be delivered via a single Ethernet connection.

This system is optimized for venues requiring flexible zoning and rapid reconfiguration. Using Dante Controller or an external DSP, users can manage one-to-one loudspeaker zoning, allowing layouts to adapt without physical re-cabling.

FLEXIBLE OUTPUT CONFIGURATION

The MX6CPOE can power up to three additional downstream (slave) speakers across two discrete
Dante audio streams:

Output 1 (Stream A): Drives the master MX6CPOE and can accommodate one additional MX6C loudspeaker. Both speakers share the same Dante audio feed.
Output 2 (Stream B): Powered by an independent Dante audio feed, this output can drive up to two additional MX6C loudspeakers. Both downstream speakers on this output receive the same signal.

Key Specifications:

• Transducers: 1″ HF & 6″ LF

• Dispersion: 130°

• Network: RJ45 Input for Dante®/AES67

• Power: Supports IEEE 802.3bt (Type 4, Class 8) PoE for up to 90W of Power

• Grilles: Black and White

SPECIFICATIONS
