Quest - QI12 - 2-Way Installation Loudspeaker, 12" LF + 1.4" HF, 8 Ohm, .
by Quest
$2,968.99
SKU QI12
Qi12
2-Way 12" Installation Loudspeaker
The Quest Qi12 represents a sophisticated evolution in permanent installation audio, combining precision engineering with elegant design. Its finely crafted timber cabinet and smooth acoustic grille integrate discreetly into architectural spaces. The 80° x 50° rotatable waveguide, paired with an integrated bi-amp/passive switch, provides flexible configuration options. Designed for seamless integration with Quest QXD amplifiers—equipped with comprehensive digital control and DSP pre-sets—the Qi12 delivers reliable, high-fidelity performance across diverse applications.
Key Specifications:
- Impedance: 8 Ω
- Transducers: 1.4″ HF & 12″ LF
- Dispersion: 80° x 50°
- Horn: Rotatable
- Power: 300W RMS
- Mounting: Horizontal & Vertical Brackets
SPECIFICATIONS
| COLOURS / MODELS |
|
||||
| FREQUENCY RESPONSE (-6 dB) | 60Hz to 18kHz | ||||
| SENSITIVITY - 1 W @ 1 m | 96.4dB | ||||
| MAXIMUM SPL @ 1 m | 127.2dB | ||||
| POWER HANDLING (RMS/PEAK) | 300W / 600W | ||||
| NOMINAL IMPEDANCE | 8Ω | ||||
| TRANSDUCERS | HF: 35mm (1.4") Compression Driver / LF: 305mm (12") Woofer | ||||
| DISPERSION (H° x V°) | 80° x 50° | ||||
| ROTATABLE HORN | Yes | ||||
| CONNECTIONS | 4-Pin Euroblock/Phoenix Connector - 7.62mm Pitch (In/Thru) | ||||
| RIGGING POINTS | Yes - See Specification Document | ||||
| DIMENSIONS (H x W x D) | 620 x 360 x 398mm (24.4" x 14.2" x 15.7") | ||||
| WEIGHT | 24.8kg (54.7lb) | ||||
| SHIPPING WEIGHT | 25.5kg (56.2lb) | ||||
| SHIPPING DIMENSIONS (H x W x D) | 755 x 490 x 450mm (29.7” x 19.3” x 17.7”) | ||||
| CABINET MATERIAL & FINISH | Marine Plywood with Polyurea Coating | ||||
| GRILLE MATERIAL & FINISH | Steel mesh with Polyester Fiber Fabric | ||||
| RECOMMENDED POWER AMPLIFIER | Quest QX or QXD Amplifiers | ||||
| ACCESSORIES (INCLUDED) | Euroblock/Phoenix Connector, Cover Plate | ||||
| ACCESSORIES (AVAILABLE SEPARATELY) | Horizontal Bracket (HBRQi12) Vertical Bracket (VBRQi12) |
