Radial Engineering - MIX-2:1 - Two-channel Audio Combiner & Mixer.
Currently Out Of Stock
$399.00
SKU MIX-2:1
Two-channel Audio Combiner & Mixer
The MIX 2:1™ is a simple yet highly useful mixer that passively sums two audio channels down to one. This enables you to easily sum the stereo outputs of a console, recording interface, or portable playback device down to mono, or to mix any two signals together and balance their relative input levels.
- Mix two channels to a single mono output
- Individual level controls can be bypassed when not in use
- Balanced 1/4″ TRS and XLR inputs
- Completely passive, no need for power
| Specifications | ||
|---|---|---|
| Audio circuit type: | Passive mixer | |
| Frequency response: | 20Hz to 20kHz | |
| Dynamic range: | >133dB | |
| Total harmonic distortion: | >0.005% @ 0dBu | |
| Intermodulation Distortion: | >0.002% @ 0dBu | |
| Phase Deviation: | 0° @ 20Hz, 0° @ 1kHz, +2° @10kHz | |
| Input Impedance: | 8 kΩ | |
| Output Impedance: | 1 kΩ | |
| Common Mode Rejection Ratio: | >80dB | |
| Noise Floor: | -113dBu | |
| Maximum Input: | >+ 20dBu | |
| Features | ||
| 180° polarity reverse, Ground lift, Level Control | ||
| Input Connectors: | 1/4", XLR | |
| Output Connectors: | XLR | |
| General | ||
| Construction: | 14-gauge steel chassis and outer shell | |
| Size (L x W x D): | 5" x 3.25" x 1.85" (12.7 x 8.3 x 4.7cm) | |
| Weight: | 1.48lb (0.67kg) | |
| Shipping size (L x W x D): | 6.25" x 4.12" x 3" (15.9 x 10.5 x 7.6cm) | |
| Shipping weight: | 1.77lb (0.8kg) | |
| Power: | Passive, no power required | |
| Conditions: | For use in dry locations only between 5°C and 40°C | |
