Sommer Cable - Isopod So-F50

$4.99
SKU 201-0406

***Price Is Per Meter***

The memory cable...

makes a clean sweep. Switchboards and racks often resemble granny's knitting pattern sheets. You ought to clean up! The? SC-Isopod SO-F50? is a 2-wire, foil-screened cable with a compact outer diameer 4,20 mm. The cable is used primarily for the internal wiring of audio and hifi components. It has a memory effect and may be easily laid around the corner. The Cu litz wires of the individual wire pairs are already pre-stranded and may be stripped very easily. For a simpler connection the cable has an extra pre-twisted and tinned drain wire. It is shielded by an AL/PT foil which will automatically stick to the jacket when stripping it down. The SC-ISOPOD SO-F50 has a larger wire cross-section (2 x 0,50 mm?) for crimp contacts.

Advantages:

  • Quick and easy to handle
  • Robust plastic jacket for long life
  • Easy to lay thanks to memory effect

Application:

  • Internal wiring of racks, audio and hifi components
  • Building Installation

???Specifications:

Name SC-Isopod SO-F50
Properties Analog
Properties OFC oxygen free copper
Application area Installation
Application Patch cable
Colour grey
Colour detailed grey
Signal transmission symmetrical
Construction (2LI2Y0,50mm)(ST)Y
Jacket material PVC
Jacket [mm] 4,20
Number of Channels (audio) 1
Inner conductor (audio) 2
Inner conductor (audio) [mm] 0,50
Inner conductor (audio) [mm] 0,80
AWG (audio) 21
Shielding AL / PT foil + AL / PT foil + filler strand, tin-plated
Copper strands (audio) 7
Copper strand (audio) [mm] 0,30
Conductor insulation material PE
Conductor insulation [mm] 1,50
Weight per 1 m [g] 58
Fire load per m [kWh] 0,07
Style variant round
Shielding factor [%] 100
Packing 200 m spool
Temperature min. [C] -25
Temperature max. [C] 70
Width [mm] 4,2
Height [mm] 4,2
Capac. cond./cond. per 1 m (audio) [pF] 100
Capacity wire/wire at 1 ft. (audio) [pF] 30,48
Capac. cond./shield. per 1 m (audio) [pF] 160
Capacity wire/electic screen at 1 ft. (audio) [pF] 48,768
Insulation resist. per 1 km [G] 0,2
Insulation resist. per 1000 feet [G] 0,061
Insulation resist. per 1 km (audio) [G] 0,2
Insulation resist. per 1000 feet (audio) [G] 0,061
Conductor resistance per 1 km 39
Conductor resistance per 1000 ft.?  11,8872
Shield. resistance per 1 km?  75
Shield. resistance per 1000 ft.?  22,86
EAN 4049371004619
