ProLink - PL-C-CAT6 - CAT6 Cable - 100% Stranded OFC Copper.
The DC6A719 is a CAT6 SF/UTP patch cable featuring stranded conductor and a flexible outer jacket which is specifically designed for Horizontal Wiring in LAN.
The conductor section of the DC6A719 consists of 4 twisted pairs with stranded copper 24 AWG conductors. The combination with hard and solid inner jacket materials and soft outer jacket materials provides great flexibility with a solid touch. Supports 10Base-T, 100Base-TX and 1000Base-T gigabit networks.
Features
- CAT6 networking patch cable
- Stranded Oxygen-free copper (OFC)
- Conductor: 24AWG (7/0.19mm)
- Filler: plastic cross
- Separator: PET
- Shielding 1 : AL/PET foil outer
- Braided shielding: 96/0.1mm, OFC
- 8.0mm (Ø) outer diameter
- Reference Standard: UL Subject 444,EIA/TIA568 & ISO/IEC 11801
- 100 Mhz performance, up to 1000Base-T
Specifications
Cable model |
DC6A719 |
Type of cable |
CAT6 UTP Network cable |
Conductor material |
Bare stranded copper |
Structure of conductor |
7 x 0.19mm |
Conductor section |
0.20 mm2 |
American wire gauge |
24 AWG |
Insulation material |
HDPE Ø1.02 |
Insulation color |
Orange / White & Orange ;Green / White & Green ; Blue / White & Blue ; Brown / White & Brown |
Number of cores |
8 (4 pairs) |
Shielding |
AL/PET foil + 96/0.1mm BC braided + drain wire |
Outer Jacket |
PVC, Black |
Outer Jacket O.D |
Ø8.0 |
