Rich and expressive, the Ten 30 is a 10 inch guitar speaker that combines warm lows with a vocal mid-range and an articulate top end. The clean sound is open and revealing; push hard and you're rewarded with full-blooded Celestion grind.
General Specifications
| Nominal diameter | 10", 254mm |
| Power rating | 30Wrms |
| Nominal impedance | Available 8Ω or 16Ω |
| Sensitivity | 95dB |
| Chassis type | Pressed steel |
| Voice coil diameter | 1.25", 31.25mm |
| Voice coil material | Round copper |
| Magnet type | Ceramic |
| Magnet weight | 13oz, 0.37kg |
| Frequency range | 85-5000Hz |
| Resonance frequency, Fs | 93.9Hz |
| DC resistance, Re | 6Ω |
Mounting Information
| Cut-out diameter | 9.0", 229mm |
| Diameter | 10.1", 256mm |
| Magnet structure diameter | 3.8", 96mm |
| Mounting slot dimensions | 0.24 x 35", 6 x 9mm |
| Mounting slot PCD | 9.6", 245mm |
| Number of mounting slots | 8 |
| Overall depth | 3.8", 96mm |
| Unit weight | 3.5lb, 1.6kg |
