Quest - QSA200i - Compact 8" Powered Speaker System
QSA200i?Compact Powered Speaker System
Small band fold-back or PA, audio visual presentation, high SPL compact audio monitor, mid power distributed systems, where ever you need compact portable or fixed full bandwidth audio, the QSA200i is a tremendously versatile powered PA package.
The high sonic output and small size is a result of the sophisticated Quest analogue engine electronics and purpose designed, heavy-duty Quest speaker components.
- 2-channel independent XLR mic/line inputs
- XLR line out with mix add function
- Long lasting heavy-duty Quest speaker components
- Uniform high frequency coverage with custom designed rotating HF horn
- Great sonic performance through analogue engine signal processing
- Micro fan cooled multi way power amplifiers
- Steel protective full front grill
Impact Resistant Plastic and Rotate the Horn
For a small speaker system, the QSA200i is packed with pro features. Multiple XLR inputs with mix output or straight through mean you can use operate the amplifier without need for a mixer on small jobs. Both line and mic level with independent level control are a handy feature.
For horizontal installation the HF horn that can be rotated to horizontal dispersion plane and an optional pan-tilt bracket can be added for both temporary or permanent installation.
Power Me Up
The QSA200i is loaded with drivers with a high power handling capacity. The cast frame ceramic mid/bass driver can take some serious power and the high frequency horn/driver combination is seriously heavy duty. The Amplification is a class A/B system for high quality analogue sound with 50 watts HF and 100 watts powering the woofer. The mini-fan cooled 2-way amplifier system is controlled by an analogue processing engine to make the QSA 200i a high output flexible and reliable choice for both live mobile audio and permanent fixes installation environments.
|Frequency response -3dB:||70 - 20K Hz|
|HF Coverage Angle||90? x 45? revolving horn flare|
|Max SPL:||123dB Peak|
|Amplifier Power:||HF 50|
|Watts LF:||100 Watts|
|Transducer:||1x 3/4" Compression driver 1 x 8" Long coil bass driver|
|Enclosure:||Injection molded plastic|
|Protective Grill:||Perforated steel acoustic foam covering|
|Installation Options:||Wall bracket/floor stand|
|Input Connections:||2 channels XLR in XLR through out|
|Dimensions HxWxD||250mm x 240mm x 430mm|
