Vendor
Eminence
Regular price
$229.99
Sale price
$229.99
Tax included.
Quantity must be 1 or more

The Eminence Legend 1218 guitar speaker brings tone to the masses. Very balanced, fat, round, punchy lows and warm, smooth mids and lows, very clean and articulate. Aces.



SPECIFICATION
Nominal Basket Diameter 12", 305 mm
Nominal Impedance* 8 Ω
Power Rating*
Program Power N/A
Watts 150 W
Resonance 100 Hz
Usable Frequency Range 80 Hz - 4.2 kHz
Sensitivity* 98.7 dB
Magnet Weight 38 oz.
Gap Height 0.312", 7.9 mm
Voice Coil Diameter 2", 51 mm
THIELE & SMALL PARAMETERS
Resonant Frequency (fs) 100 Hz
DC Resistance (Re) 6.95 Ω
Coil Inductance (Le) 0.69m H
Mechanical Q (Qms) 15.51
Electromagnetic Q (Qes) 0.95
Total Q (Qts) 0.89
Compliance Equivalent Volume (Vas) 31.2 liters / 1.1 cu.ft.
Peak Diaphragm Displacement Volume (Vd) 40.5 cc
Mechanical Compliance of Suspension (Cms) 0.09 mm/N
BL Product (BL) 11.6 T-M
Diaphragm Mass Inc. Airload (MMs) 29 grams
Efficiency Bandwidth Product (EBP) 105
Maximum Linear Excursion (Xmax) 0.8 mm
Surface Area of Cone (Sd) 506.7 cm2
Maximum Mechanical Limit (Xlim) N/A
MOUNTING INFORMATION
Recommended Enclosure Volume
Sealed N/a
Vented Acceptable
Driver Volume Displaced 0.071 cu.ft. / 2 liters
Overall Diameter 12.03", 305.6 mm
Baffle Hole Diameter 11.07", 281.2 mm
Front Sealing Gasket Yes
Rear Sealing Gasket Yes
Mounting Holes Diameter 0.25", 6.4mm
Mounting Holes B.C.D. 11.59", 294.4mm
Depth 5.1", 129.5 mm
Net Weight 8.4 lbs, 3.81 kg
Shipping Weight 10.6 lbs, 4.81 kgs
MATERIALS OF CONSTRUCTION
Coil Construction Copper voice coil
Coil Former Polyimide former
Magnet Composition Ferrite magnet
Core Details Non-vented core

Basket Materials Pressed steel basket
Cone Composition Paper cone
Cone Edge Composition Paper cone edge
Dust Cap Composition Zurette dust cap
